12V System40A MPPT
12V Hybrid Solar System
Anern ES-1000W
A no-frills 1kW 12V unit for a small off-grid room or cabin backup — runs 8 LED lights, 2 fans, a TV, an inverter fridge, and phone charging simultaneously. The 40A MPPT accepts up to 560W of solar panels with no wireless monitoring included.
Power
1.0 kW
Battery
12 V
Charge
40 A
Prices shown are estimated retail prices. No online store link available yet.
Technical Blueprint
Deep dive into the electrical capabilities of the Anern 1.0kW series.
Solar & PV Input
- Max Array
- 559 W
- Max Voltage
- 150 V
- MPPT Range
- 20–150V
- MPPT Current
- 40 A
AC Output Specs
- Rated Output
- 1,000 W
- Voltage
- 220 V
- Waveform
- Pure Sine
Battery Logic
- Chemistry
- Lead-Acid / AGM
- Nominal V
- 12 V
- Max Charge
- 40 A
Build Quality
- Net Weight
- 3 kg
- Type
- All-in-One Hybrid
Wiring Specs
Breaker rating and wire gauge for every run on the Anern 1.0kW — sized at its rated output.
Battery breaker
125A DC
Battery cable
2 AWG
AC load breaker
10A AC
PV cable
10 AWG
What can it actually
run?
Most people buy these for brownouts or bill reduction. Here is a realistic scenario of a 1,000W unit supporting a typical Filipino household's daytime loads.
Total DemandActive Load
787W
Safezone: you still have 213W headroom for surges (pumps, kettles, etc.)
LED bulb (8×)
72W
Electric fan (2×)
120W
LED/Smart TV
150W
Laptop charger
65W
Smartphone charger (5×)
50W
Refrigerator – i…
250W
Water dispenser …
80W
