24V System40A MPPT
24V Hybrid Solar System
Anern ES-1000W
A 1.5kW 24V unit for a small Filipino home — powers lights, fans, a TV, an inverter fridge, and multiple devices simultaneously on a 24V battery system. The 40A MPPT accepts up to 1,080W of solar panels with no wireless monitoring.
Power
1.5 kW
Battery
24 V
Charge
40 A
Prices shown are estimated retail prices. No online store link available yet.
Technical Blueprint
Deep dive into the electrical capabilities of the Anern 1.5kW series.
Solar & PV Input
- Max Array
- 1,080 W
- Max Voltage
- 150 V
- MPPT Current
- 40 A
AC Output Specs
- Rated Output
- 1,500 W
- Voltage
- 220V ±5% (Adjustable)
- Waveform
- Pure Sine
Battery Logic
- Chemistry
- Lead-Acid / AGM
- Nominal V
- 24 V
- Max Charge
- 40 A
Build Quality
- Net Weight
- 3.5 kg
- Type
- All-in-One Hybrid
Wiring Specs
Breaker rating and wire gauge for every run on the Anern 1.5kW — sized at its rated output.
Battery breaker
80A DC
Battery cable
4 AWG
AC load breaker
10A AC
PV cable
10 AWG
What can it actually
run?
Most people buy these for brownouts or bill reduction. Here is a realistic scenario of a 1,500W unit supporting a typical Filipino household's daytime loads.
Total DemandActive Load
885W
Safezone: you still have 615W headroom for surges (pumps, kettles, etc.)
LED bulb (10×)
90W
Electric fan (3×)
180W
LED/Smart TV
150W
Laptop charger
65W
Smartphone charger (5×)
50W
Refrigerator – i…
250W
Water dispenser
80W
Wi-Fi router
20W
