12V System40A MPPT
12V Hybrid Solar System
ECG 1.0kW
Sized for a small off-grid room or emergency backup in the Philippines — runs 8 LED lights, 2 fans, a TV, an inverter fridge, and 5 phones simultaneously on a 12V battery bank. Wireless monitoring and a 40A MPPT accepting up to 600W of solar panels make it a simple, self-contained starter kit.
Power
1.0 kW
Battery
12 V
Charge
40 A
Prices vary by vendor. Purchasing via these links supports SolarPanda research at no extra cost to you.
Technical Blueprint
Deep dive into the electrical capabilities of the ECG 1.0kW series.
Solar & PV Input
- Max Array
- 600 W
- Max Voltage
- 150 V
- MPPT Current
- 40 A
AC Output Specs
- Rated Output
- 1,000 W
- Voltage
- 220V ±5% (Adjustable)
- Waveform
- Pure Sine
Battery Logic
- Chemistry
- LiFePO4 / AGM
- Nominal V
- 12 V
- Max Charge
- 40 A
Build Quality
- Net Weight
- 3.0 kg
- Type
- All-in-One Hybrid
Wiring Specs
Breaker rating and wire gauge for every run on the ECG 1.0kW — sized at its rated output.
Battery breaker
125A DC
Battery cable
2 AWG
AC load breaker
10A AC
PV cable
10 AWG
What can it actually
run?
Most people buy these for brownouts or bill reduction. Here is a realistic scenario of a 1,000W unit supporting a typical Filipino household's daytime loads.
Total DemandActive Load
787W
Safezone: you still have 213W headroom for surges (pumps, kettles, etc.)
LED bulb (8×)
72W
Electric fan (2×)
120W
LED/Smart TV
150W
Laptop charger
65W
Smartphone charger (5×)
50W
Refrigerator – i…
250W
Water dispenser …
80W
